iWindow Fixed Flat Roof Window 100x300 cm
Een Skylux opstand is nodig voor correcte installatie. Bij plaatsing op een bestaande (niet Skylux) opstand, adviseren we een renovatiekader tussen de opstand en het nieuwe raam of koepel.
Popular accessories
iWindow Fixed Flat Roof Window 100x300 cm
Product details
Ug value (U-value of the glazing or insulation value of the glazing in W/m²K)
iWindow2
- Clear: 1.00 W/m²K
- Opal: 1.00 W/m²K
- Solar control: 1.00 W/m²K
iWindow3
- Clear: 0.50 W/m²K
- Opal: 0.50 W/m²K
- Solar control: 0.50 W/m²K
Urc value Skylux® iWindow with curb (W/m²K)
- iWindow2
- iWindow3
LT value (Light transmission in %)
iWindow2
- Clear: 75%
- Opal: 72%
- Solar control: 53%
iWindow3
- Clear: 63%
- Opal: 61%
- Solar control: 46%
g-value (Total solar energy transmittance in %)
iWindow2
- Clear: 52%
- Opal: 50%
- Solar control: 40%
iWindow3
- Clear: 42%
- Opal: 41%
- Solar control: 33%
Rw value (Acoustic attenuation index in dB)
- iWindow2: 39 dB
- iWindow3: 41 dB
Additional properties
iWindow2
- Clear:
- Thickness: ± 39 mm
- Weight (kg/m²): ± 35 to 44 kg/m²
- Mechanical property: Layered (inner pane) and tempered (outer pane)
- Opal:
- Thickness: ± 39 mm
- Weight (kg/m²): ± 35 to 44 kg/m²
- Mechanical property: Layered (inner pane) and tempered (outer pane)
- Solar control:
- Thickness: ± 39 mm
- Weight (kg/m²): ± 35 to 44 kg/m²
- Mechanical property: Layered (inner pane) and tempered (outer pane)
iWindow3
- Clear:
- Thickness: ± 61 mm
- Weight (kg/m²): ± 55 to 60 kg/m²
- Mechanical property: Layered (inner pane) and tempered (outer and middle pane)
- Opal:
- Thickness: ± 61 mm
- Weight (kg/m²): ± 55 to 60 kg/m²
- Mechanical property: Layered (inner pane) and tempered (outer and middle pane)
- Solar control:
- Thickness: ± 61 mm
- Weight (kg/m²): ± 55 to 60 kg/m²
- Mechanical property: Layered (inner pane) and tempered (outer and middle pane)
Specifications and manuals.
All documentation for design, specification, and installation. Technical files, installation manuals, and drawings - ready to download.
